Tractor Mounted Pole Erection Machine Price India
Lift and erect electric poles with power, safety, and precision.
The Tractor Mounted Pole Erection Machine is a robust hydraulic system designed to lift, transport, and erect electric poles effortlessly. B...
Watch it in Action
Product Specifications
Comprehensive details to ensure perfect fit and performance.
| Brand | PowerAgro Industries |
| Delivery | Pan India Delivery (Shipped from Our Manufacturing Unit) |
| Model Number | PA-PEM-02 |
| Lifting Capacity | Up to 1.7 Tons |
| Max Vertical Lifting Height | 22 Feet (from Ground) |
| Show All Specifications | |
Available Variants
Choose the perfect model for your requirements
PowerAgro PMX-22S
Model: PA-PEM-22-STD
Standard 3-jack entry model designed for lifting and placing light to medium electric poles. Operates on tractor's built-in hydraulics.
Key Features
- 3 heavy-duty hydraulic cylinders (2 boom lift, 1 telescopic extension)
- Lifts PCC electric poles up to 1.2 Tons
- Vertical reach up to 22 Feet from ground level
- Horizontal boom extension up to 20 Feet
- Operates on standard tractor hydraulics (dual auxiliary valve required)
- Subframe chassis rail mounting for secure load distribution
Benefits
- 36.5cc PTO pump and 90L oil tank kit
- Replacement pin-and-bush set
PowerAgro PMX-22P
Model: PA-PEM-22-PRO
3-jack pole erection machine equipped with an independent PTO-driven gearbox and 36.5cc hydraulic pump system with a 90L reservoir.
Key Features
- 3 heavy-duty hydraulic cylinders (2 boom lift, 1 telescopic extension)
- Lifts PCC electric poles up to 1.2 Tons
- Includes dedicated PTO multiplier gearbox & heavy-duty 36.5cc hydraulic pump
- 90 Liters integrated hydraulic oil tank with return line filter
- Vertical reach up to 22 Feet; Horizontal reach up to 20 Feet
- Does not put stress on tractor's internal hydraulic pump
Benefits
- Heavy-duty PTO Cardan shaft
- Subframe reinforcing plates
PowerAgro PMX-22S-S
Model: PA-PEM-22-S-STD
5-jack model featuring dual hydraulic stabilizer legs (outriggers) to provide enhanced ground stability on uneven terrain. Runs on tractor hydraulics.
Key Features
- 5 heavy-duty hydraulic cylinders (2 boom lift, 1 extension, 2 ground outriggers)
- Lifts PCC electric poles up to 1.5 Tons
- Dual hydraulic stabilizers for perfect leveling on soft/muddy terrain
- Vertical reach up to 22 Feet; Horizontal reach up to 20 Feet
- Operates on tractor's built-in hydraulic system
- Reinforced pivot pins with greasable phosphor bronze bushings
Benefits
- 36.5cc PTO pump and 90L oil tank kit
- Extra-wide steel stabilizer mud pads
PowerAgro PMX-22S-P
Model: PA-PEM-22-S-PRO
5-jack outrigger model with dedicated independent PTO-driven 36.5cc hydraulic system and 90L reservoir for reliable continuous duty.
Key Features
- 5 heavy-duty hydraulic cylinders (2 boom lift, 1 extension, 2 ground outriggers)
- Lifts PCC electric poles up to 1.5 Tons
- Includes dedicated PTO multiplier gearbox & heavy-duty 36.5cc hydraulic pump
- 90 Liters integrated hydraulic oil tank with return line filter
- Dual hydraulic stabilizers for perfect leveling on soft/muddy terrain
- High-pressure hoses and dedicated multi-spool directional valves
Benefits
- Heavy-duty PTO Cardan shaft
- Extra-wide steel stabilizer mud pads
PowerAgro PMX-22A-P
Model: PA-PEM-22-A-PRO
Advanced 7-jack model equipped with a hydraulic auger drilling system, outriggers, and boom. Digs holes up to 10 ft deep and 22" diameter. Operates on tractor hydraulics.
Key Features
- 7 hydraulic cylinders (2 boom lift, 1 extension, 2 stabilizers, 2 auger control)
- Integrated hydraulic auger drive motor for high-torque drilling
- Auger drilling: up to 10 Feet deep and 22 Inches diameter
- Lifts PCC electric poles up to 1.7 Tons
- Vertical reach up to 22 Feet; Horizontal reach up to 20 Feet
- Operates on tractor's built-in hydraulics
Benefits
- 61cc PTO pump and 120L oil tank kit
- Replacement auger flighting (12", 18", or 22" diameters)
PowerAgro PMX-22M
Model: PA-PEM-22-A-MAX
Ultimate configuration for contracting crews. Features the 7-jack auger & stabilizer system driven by a high-flow 61cc PTO pump and a large 120L reservoir.
Key Features
- 7 hydraulic cylinders (2 boom lift, 1 extension, 2 stabilizers, 2 auger control)
- Auger drilling: up to 10 Feet deep and 22 Inches diameter with high-torque motor
- Includes high-performance PTO multiplier gearbox & 61cc heavy-duty pump
- Large 120 Liters hydraulic oil tank with level indicator and return line filter
- Lifts PCC electric poles up to 1.7 Tons
- Designed for high-frequency daily operation without oil overheating
Benefits
- Heavy-duty PTO Cardan shaft
- Replacement auger flighting (12", 18", or 22" diameters)
- Dual-control valve system upgrade
Key Features
Trust & Warranty
Other Names
This product is also commonly referred to as Electric Pole Lifter, Pole Erection Machine with Tractor, Tractor Pole Erection Attachment, Tractor Mounted Pole Lifter, Hydraulic Pole Erection Machine, Electric Pole Erector, Pole Erecting Hydraulic Machine, Tractor Post Pole Erection System. Whatever the name, it represents the same reliable quality from our company.
