Tractor Front Loader Attachment
Transform your tractor into a JCB - heavy duty front loader for agriculture and construction.
The PowerAgro Tractor Front Loader Attachment converts any standard Indian tractor into a powerful JCB-type loader capable of handling sand,...
Product Specifications
Comprehensive details to ensure perfect fit and performance.
| Brand | PowerAgro Industries |
| Tractor HP Required | 30 HP - 75 HP+ |
| Max Lift Capacity | 500 Kg - 1500+ Kg (Model Dependent) |
| Max Lift Height | 12 Feet - 14 Feet (Model Dependent) |
| Bucket Widths | 5.0 Feet / 5.5 Feet / 6.0 Feet |
| Show All Specifications | |
Bucket Sizes & Effective Material Capacities
Effective bucket capacities are based on actual bucket geometry and recommended tractor configurations.
| Part Code | Recommended Tractor | Dimensions (Feet) | Effective Bucket Capacity (m³) | Estimated Material Weight* (kg) |
|---|---|---|---|---|
| PA-LB-35 | 35 HP | 5.0' × 2.0' × 2.5' | 0.584 | ~900 |
| PA-LB-40 | 40 HP+ | 5.5' × 2.0' × 2.5' | 0.642 | ~1,000 |
| PA-LB-40HD | 40 HP+ | 5.5' × 2.5' × 2.5' | 0.803 | ~1,200 |
| PA-LB-45 | 45 HP+ (4WD) | 5.5' × 3.0' × 2.5' | 0.964 | ~1,400 |
| PA-LB-45HD | 45 HP+ (4WD) | 6.0' × 3.0' × 2.5' | 1.051 | ~1,600 |
| PA-LB-50 | 50 HP+ / Commercial (4WD) | 6.0' × 3.0' × 3.0' | 1.262 | ~1,900 |
Disclaimer & Important Notes
- *Estimated material weights are calculated using a standard bulk density of 1,500 kg/m³ (dry soil/loose earth).
- Effective bucket capacity is determined using actual bucket geometry, including the curved floor, rear profile, and side-wall design, rather than simple rectangular dimensions.
- Estimated material weight is provided for reference only and must not be interpreted as the loader's Safe Working Load (SWL).
- Actual lifting capacity depends on tractor model, hydraulic performance, rear ballast, tyre configuration, terrain conditions, and material density.
- Material density, moisture content, and heaped loading conditions may significantly affect actual payload.
Available Variants
Choose the perfect model for your requirements
PowerAgro FLX-3S
Model: PA-FL-30-STD
Entry level 4-jack loader running on tractor's existing hydraulics. Ideal for general agriculture and light construction material handling on 30–40 HP tractors.
Key Features
- 4 heavy-duty hydraulic jacks (2 boom lift + 2 bucket dump/fill)
- Compatible with 30–40 HP tractors (Mahindra 475, Swaraj 735, Eicher 380)
- Runs on tractor's inbuilt hydraulics -no external pump needed
- Lifting capacity: 500–800 Kg
- Loader hinge pin height: 12 Feet
- Compatible buckets: PA-LB-35 (5.0 ft) and PA-LB-40 (5.5 ft)
- Best for general agriculture, manure loading, and light soil handling
Benefits
- Optional independent PTO hydraulic pump
- Quick-detach mounting frame
PowerAgro FLX-4P
Model: PA-FL-40-PRO
Upgraded 4-jack loader with dedicated Veljan vane pump and independent oil tank for faster cycle times and maximum lifting power on 40–50 HP tractors.
Key Features
- 4 heavy-duty hydraulic jacks (2 boom lift + 2 bucket dump/fill)
- Compatible with 40–50 HP+ tractors -2WD or 4x4
- PTO multiplier gearbox + Veljan VTXB2 (36.5 cc) vane pump
- Flow rate: 34.3 LPM | Operating pressure: 140 bar
- Oil tank: 90 Ltr | Hose: 1" suction / ½" pressure
- Lifting capacity: 800–1200 Kg
- Loader hinge pin height: 12 Feet
- Compatible buckets: PA-LB-40HD and PA-LB-45 (5.5 ft)
Benefits
- Heavy-duty rear counterweight box
- Quick-detach mounting frame
PowerAgro FLX-4.5G
Model: PA-FL-45-G-STD
6-jack loader with hydraulic grabber clamp for handling bulky materials like sugarcane, cotton bales, and logs. Runs on tractor hydraulics.
Key Features
- 6 heavy-duty hydraulic jacks (boom lift + dump/fill + grabber gate)
- Compatible with 45–60 HP tractors -4x4 recommended (John Deere 5310, Swaraj 855)
- Runs on tractor's inbuilt hydraulics (external pump kit available as upgrade)
- Loader hinge pin height: 12 Feet
- High-strength steel grabber jaws with integrated grip teeth
- Compatible buckets: PA-LB-40HD and PA-LB-45 (5.5 ft) grabber buckets
- Best for sugarcane loading, cotton bales, tree logs, and green waste
Benefits
- Sugarcane grabber attachment
- Triple-spool valve extension kit
- Optional independent PTO hydraulic pump
PowerAgro FLX-5G
Model: PA-FL-50-G-PRO
Ultimate 6-jack grabber loader with dedicated Veljan vane pump for heavy industrial workloads at sugarcane mills and commercial timber handling.
Key Features
- 6 heavy-duty hydraulic jacks (boom lift + dump/fill + grabber gate)
- Compatible with 50–75 HP+ tractors -4x4
- PTO multiplier gearbox + Veljan VTXB2 (46 cc max) vane pump
- Flow rate: 43.2 LPM | Operating pressure: 160 bar
- Oil tank: 115 Ltr baffle partition | Hose: 1¼" suction / ¾" pressure
- Loader hinge pin height: 12 Feet
- Compatible buckets: PA-LB-45HD and PA-LB-50 (6.0 ft) grabber buckets
- Best for sugarcane mills, paper pulp plants, and high-frequency commercial timber loading
Benefits
- Sugarcane grabber attachment
- Heavy-duty rear counterweight box
PowerAgro FLX-5T
Model: PA-FL-50-T-STD
6-jack telescopic loader with extending arms for extra loader hinge pin height up to 13.5 feet. Ideal for loading rice husk trucks, cotton, and standard commercial dumpers.
Key Features
- 6 heavy-duty hydraulic jacks (boom lift + dump/fill + telescopic extending arms)
- Compatible with 50–65 HP tractors -2WD or 4x4
- Runs on tractor's inbuilt hydraulics (external pump kit available as upgrade)
- Telescopic boom: additional 3.5 feet reach
- Loader hinge pin height: 13.5 Feet
- Compatible buckets: PA-LB-45 (5.5 ft) and PA-LB-45HD (6.0 ft)
- Best for rice husk trucks, cotton loading, and standard commercial dumpers
Benefits
- Optional independent PTO hydraulic pump
- Heavy-duty rear counterweight box
PowerAgro FLX-5.5T
Model: PA-FL-55-T-MAX
Maximum loader hinge pin height and extreme productivity. Dedicated Veljan VT6C vane pump with submerged return tank. Reaches 14 feet for industrial hoppers and 14–16 wheeler trucks.
Key Features
- 6 heavy-duty hydraulic jacks (boom lift + dump/fill + telescopic extending arms)
- Compatible with 55–75 HP+ heavy-duty tractors -4x4
- PTO multiplier gearbox + Veljan VT6C (61 cc) vane pump
- Flow rate: 57.3 LPM | Operating pressure: 180 bar
- Oil tank: 145 Ltr submerged return | Hose: 1½" suction / ¾" multi-spiral
- Telescopic boom: additional 3.5 feet reach
- Loader hinge pin height: 14 Feet
- Compatible buckets: PA-LB-50 (6.0 ft) commercial bulk handling bucket
- Best for industrial hoppers and high-body tipper trucks (14–16 wheelers)
Benefits
- Heavy-duty rear counterweight box
- Independent high-flow control valves
Key Features
Trust & Warranty
Other Names
This product is also commonly referred to as Tractor Front Loader, Tractor Loader, Tractor Front End Loader, Tractor Loader Attachment, Tractor JCB Attachment, JCB Type Tractor Loader, Tractor Wala Loader, Bull Loader Tractor, Bull Tractor Attachment, Tractor Bucket Attachment, Agriculture Loader, Front Loader Implement, Heavy Duty Tractor Loader, Tractor Mounted Loader, Tractor Mitti Loader, Mahindra Tractor Loader, Swaraj Tractor Loader, Loader Machine Tractor. Whatever the name, it represents the same reliable quality from our company.
